2 in stock (can be backordered)
• 4 Digits LCD Display
• Auto Range For MΩ & Ω
• 40 Segments Analog Display
• Test Hold Function For Easy Operation
• Automatic Zero To Null Lead Resistance
• Easy To Carry
• Discharge Indication Beeper For MΩ Range
• >1mA Test Current For MΩ Range At Rated Voltage
• >200mA Short Current For Continuity Range
| Function | Range | Resolution | Accuracy |
|---|---|---|---|
| ACV | 600V | 0.1V | 1.5%rdg+3dgts |
| DCV | 600V | 0.1V | 1%rdg+3dgts |
| Ω | 400Ω~4000Ω | 0.1Ω~10KΩ | 1%rdg+5dgts |
| MΩ | 4/40/400/4000MΩ (250V/500V/1000V) |
1KΩ~1MΩ | 3%rdg+5dgts |
| •)))_Active Sound Level | ≦ 40Ω | ||
| Display: 76x42mm LCD panel with 40 segments analog bar indication |
| Sampling Rate: 2.5 times/sec digital display; 10 times/sec bar graph |
| Battery: 1.5V size AA battery x 8 |
| Dimensions: 196x112x64 mm |
| Weight: 700g |
